DN25-DN3000 100mm 150mm 200mm Rubber Expansion Joint Concentric Equal Nominal Diameter Range

Name: DN25-DN3000 100mm 150mm 200mm Rubber Expansion Joint Concentric Equal Nominal Diameter Range
Brand: Henan Zhicheng Valve Fittings Manufacturing Co., Ltd.
SKU: ZCF-310
Price: 13.00 USD
Availability: InStock

Product Details

Place of Origin: Henan, China

Brand Name: ZHICHENG

Model Number: ZCF-310

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $16.90/pieces 10-98 pieces

Packaging Details: Rubber expansion joint is packed by:
plastic film with carton case, and then put into standard wooden case.

Supply Ability: 10000 Set/Sets per Month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                  100mm expansion joint, 150mm expansion joint, 200mm expansion joint


Warranty:	1year	Customized Support:	ODM, OEM
Technics:	Forged	Connection:	Flange
Shape:	Equal	Head Code:	Round
Product Name:	Flexible Joint Rubber Expansion Bellows	Rubber Material:	EPDM, CR, NBR, NEOPRENE
Nominal Diameter:	DN25-DN3000	Line Type:	Flange End Or Thread End
Flange Standard:	DIN, BS, JIS, ANSI	Applicable Temperature:	-15~80℃(Special -30~150℃)
Applicable Media:	Air, Water, Sewage, Sea Water, Acid, Alkali, Oil Etc	Working Pressure:	6-40bars
Test Pressure:	1.5 Times Of Working Pressure	Explosion Pressure:	2 Times Of Working Pressure
Port:	Qingdao Port Or Negotiable

Warranty:	1year
Customized Support:	ODM, OEM
Technics:	Forged
Connection:	Flange
Shape:	Equal
Head Code:	Round
Product Name:	Flexible Joint Rubber Expansion Bellows
Rubber Material:	EPDM, CR, NBR, NEOPRENE
Nominal Diameter:	DN25-DN3000
Line Type:	Flange End Or Thread End
Flange Standard:	DIN, BS, JIS, ANSI
Applicable Temperature:	-15~80℃(Special -30~150℃)
Applicable Media:	Air, Water, Sewage, Sea Water, Acid, Alkali, Oil Etc
Working Pressure:	6-40bars
Test Pressure:	1.5 Times Of Working Pressure
Explosion Pressure:	2 Times Of Working Pressure
Port:	Qingdao Port Or Negotiable

Description

DN25-DN3000 100mm 150mm 200mm Rubber Expansion Joint Concentric Equal Nominal Diameter Range

DN25-DN3000 Concentric Rubber Expansion Joint with Equal Nominal

Diameter Range Options

Good Elasticity Vibration And Noise Reduction Ss304 Flange Connection Flexible Joint Single

Sphere Rubber Expansion Bellows

choose the products of ZHICHENG ?
1.24 hours online service-- anytime, anywhere can provide what you want.
2.100% quality inspection before shippment.
3.Strong production capability and strict quality control.

Product Description

Rubber expansion joints consist of inner and outer rubber, cord layer and steel wire strand, which are vulcanized and then

combined with metal flanges or loose sleeves of parallel joints. It is widely used in various pipeline systems.

No	Name	Material
1	Outer/inner rubber	NR, EPDM, NBR, Neoprene etc.
2	Frame	Nylon cord fabric
3	Pressurized ring	Steel wire strand
4	Flange	Carbon steel galvanized, paint ductile iron, stainless steel etc.

Operation condition
Working temperature	-15℃~80℃(-30℃~150℃)
Working pressure	6-40bars(PN6-PN40)
Test pressure	1.5 times of working pressure
Explosion pressure	2 times of working pressure
Applicable media	Air, water, sewage, sea water, acid, alkali, oil etc.

Main connection dimension
Nominal diameter		Length (mm)	Axial displacement		Horizontal movement (mm)	Deflection angle (a1+a2)°	Special length (mm)
mm	inch	Length (mm)	Compression (mm)	Extension (mm)	Horizontal movement (mm)	Deflection angle (a1+a2)°	Special length (mm)
32	1 1/4	95	9	6	9	15°	130/150/200
40	1 1/2	95	10	6	9	15°	130/150/200
50	2	105	10	7	10	15°	130/150/200
65	2 1/2	115	13	7	11	15°	130/150/200
80	3	135	15	8	12	15°	130/150/200
100	4	150	19	10	13	15°	130/200
125	5	165	19	12	13	15°	130/150/200
150	6	180	20	12	14	15°	130/150/200
200	8	210	25	16	22	15°	130/150/200
250	10	230	25	16	22	15°	130/150/200
300	12	245	25	16	22	15°	130/150/200
350	14	255	25	16	22	15°	130/150/200
400	16	255	25	16	22	15°	130/150/200
450	18	255	25	16	22	15°	200
500	20	255	25	16	22	15°	200
600	24	260	25	16	22	15°	300

( Note: Size range from DN25-3000 are all available, special size and length can also be customizedplease contact us

for exact data.

DN25-DN3000 100mm 150mm 200mm Rubber Expansion Joint Concentric Equal Nominal Diameter Range 1

The rubber expansion joints allow for four way movements, and they are molded from synthetic rubber and nylon cord,

and this can reduce vibration and noise, and compensate thermal expansion and contraction caused by temperature change.

DN25-DN3000 100mm 150mm 200mm Rubber Expansion Joint Concentric Equal Nominal Diameter Range 2

Technical parameter

DN25-DN3000 100mm 150mm 200mm Rubber Expansion Joint Concentric Equal Nominal Diameter Range 3

Production

ZHICHENG has a strict quality control system, the standard production process, standardized factory testing means to

ensure that every product to meet the customer requirements, and provide customers with high-quality products.

DN25-DN3000 100mm 150mm 200mm Rubber Expansion Joint Concentric Equal Nominal Diameter Range 4

Packaging & Shipping

Packaging

1.Inner package: plastic film with carton cases.
2.Outer package: wooden cases(usually the size of 1100mm*1100mm*1100mm).

DN25-DN3000 100mm 150mm 200mm Rubber Expansion Joint Concentric Equal Nominal Diameter Range 5

Product installation

When the customer installs, we will provide installation instructions, installation notes and maintenance instructions. and this is the installation picture of the DN1800 rubber expansion joint.

DN25-DN3000 100mm 150mm 200mm Rubber Expansion Joint Concentric Equal Nominal Diameter Range 7
