Product Details
Place of Origin: Henan, China
Brand Name: zhicheng
Model Number: ZCH
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $12.10/sets >=10 sets
Warranty: |
1year |
Customized Support: |
OEM, ODM |
Technics: |
Stamping |
Connection: |
Bolted Connections |
Shape: |
Equal |
Head Code: |
ROUND |
Place Of Origin:: |
Henan, China |
Certificate:: |
ISO9001, TUV, WRAS, CO, MTC, PL, IV Etc |
Model Number:: |
ZCH |
Connection:: |
Bolted Connect |
Size:: |
DN25 - DN500 |
MOQ:: |
1 Piece |
Packing:: |
Wooden Case |
Usage:: |
Pipe Quick Easy Pipe Repair Clamp |
Seal Ring Material:: |
NR, EPDM, NBR, Neoprene,etc |
Application:: |
Water, Gas, Oil, Etc. |
Warranty: |
1year |
Customized Support: |
OEM, ODM |
Technics: |
Stamping |
Connection: |
Bolted Connections |
Shape: |
Equal |
Head Code: |
ROUND |
Place Of Origin:: |
Henan, China |
Certificate:: |
ISO9001, TUV, WRAS, CO, MTC, PL, IV Etc |
Model Number:: |
ZCH |
Connection:: |
Bolted Connect |
Size:: |
DN25 - DN500 |
MOQ:: |
1 Piece |
Packing:: |
Wooden Case |
Usage:: |
Pipe Quick Easy Pipe Repair Clamp |
Seal Ring Material:: |
NR, EPDM, NBR, Neoprene,etc |
Application:: |
Water, Gas, Oil, Etc. |
1.Strong corrosion resistance
2.No need for welding
3.No fire hazard
4.Space saving
5.Unlimited pipe material
6.Pressure sealing
7.Easy installation
Specification
| 产 品 规 格 Product Specification | ||||
| 适用管径 Applicable Pipes Diameter |
工业允用压力 Allowable Pressure of Industry |
长度范围 Length Range |
螺栓 Bolt |
扭矩 Torque |
| ODmin-ODmax(mm) | WP(bar) | S(MM) | M | NM |
| 88-108 | 16 | 150-600 | 14 | 80 |
| 108-128 | 16 | 150-600 | 14 | 80 |
| 113-133 | 16 | 150-600 | 14 | 80 |
| 120-141 | 16 | 150-600 | 14 | 80 |
| 168-188 | 16 | 150-600 | 14 | 80 |
| 174-194 | 16 | 150-1200 | 14 | 80 |
| 219-239 | 16 | 150-1200 | 16 | 100 |
| 228-249 | 16 | 150-1200 | 16 | 100 |
| 238-258 | 16 | 150-1200 | 16 | 100 |
| 258-278 | 16 | 150-1200 | 16 | 100 |
| 273-293 | 16 | 150-1200 | 16 | 100 |
| 282-302 | 10 | 150-1200 | 16 | 100 |
| 29-5315 | 10 | 150-1200 | 16 | 100 |
| 324-344 | 10 | 150-1200 | 16 | 120 |
| 335-356 | 10 | 150-1200 | 16 | 120 |
| 347-367 | 10 | 150-1200 | 16 | 120 |
| 357-376 | 10 | 150-1200 | 16 | 120 |
| 365-384 | 10 | 150-1200 | 16 | 120 |
| 383-402 | 10 | 150-1200 | 16 | 120 |
| 404-423 | 10 | 150-1200 | 16 | 120 |
| 421-440 | 10 | 150-1200 | 16 | 120 |
| 436-455 | 10 | 150-1200 | 16 | 120 |
| 453-472 | 10 | 150-1200 | 16 | 120 |
| 469-488 | 10 | 150-1200 | 16 | 120 |
| 488-507 | 10 | 150-1200 | 16 | 130 |
| 505-525 | 10 | 150-1200 | 16 | 130 |
| 526-545 | 8 | 150-1200 | 16 | 130 |
| 547-566 | 8 | 150-1200 | 16 | 130 |
| 582-581 | 8 | 150-1200 | 16 | 130 |
| 582-601 | 8 | 150-1200 | 16 | 130 |
| 630-650 | 8 | 150-1200 | 16 | 130 |
| 670-690 | 8 | 150-1200 | 16 | 130 |
| 720-740 | 8 | 150-1200 | 16 | 130 |
